Installation of steel pipes for Air Jack 60C
Mounting accessories for mounting the Nuke Performance Air Jack 60C. Enables easy installation thanks to accurate measurements.
Made of steel and intended to be welded to the body or chassis. Delivered untreated and ready to apply. Adjust external dimensions to suit your needs and purposes.
Length: 225mm (8.86") *
Thickness: 2mm (0.08)")
Hole Ø : 62.5mm (2.46")
Material : Steel
Weight : 661g (1.45lb)
* The tube can be split into three shorter sections for use as either low or high mounting points, with a recommended length of 64mm (2.52") for each section.
We recommend that each air jack is supported by both upper and lower mounting points or by a pipe bracket attached to both low and high mounting points. Make sure the mounting points are installed securely and correctly.
• Nuke Performance Air Jack 60C Mounting Accessories
Nuke Performance has developed a range of mounting accessories to make installing the Air Jack 60C as easy as possible. A plate, bracket and tube are available, all in weldable steel and adapted for direct mounting of the Air Jack 60 C to your chassis. All parts are easy to adapt to your intended dimensional needs.
Steel plate Part # : 580-10-017
Steel bracket Part # : 580-10-018
Steel pipe / Pipe Part # : 580-10-019
• Download user manual (.pdf)
• Accessories / Spare parts
Quantity: 1 pc
